Базовые характеристики
Access control
Flexible access control of SSH, Web interface, CLI and Telnet
Antennas
2 x SMA for LTE, 1 x SMA for GNNS
Applications
Samba share, USB-to-serial
Attack prevention
DDOS prevention (SYN flood protection, SSH attack prevention, HTTP/HTTPS attack prevention), port scan prevention (SYN-FIN, SYN-RST, X-mas, NULL flags, FIN scan attacks)
Authentication
Pre-shared key, digital certificates, X.509 certificates, TACACS+, Internal & External RADIUS users authentication, IP & login attempts block, time-based login blocking, built-in random password generator
AWS IoT Core
Utility to interact with the AWS cloud platform. Jobs Support: Call the device's API using AWS Jobs functionality
Azure IoT Hub
Can be configured with Data to Server to send all the available parameters to the cloud. Has Direct method support which allows to execute RutOS API calls on the IoT Hub. Also has Plug and Play integration with Device Provisioning Service that allows zero-touch device provisioning to IoT Hubs
Band management
Band lock, Used band status display
Block/Allow list
Operator block/allow list (by country or separate operators)
Bridge
Direct connection (bridge) between mobile ISP and device on LAN
Call
Reboot, Status, Mobile data on/off, Output on/off, answer/hang-up with a timer, Wi-Fi on/off
Casing material
Aluminium housing
Certificate Manager
Certificate creation tool allows to create CA, server, client, let's encrypt, SCEP certificates
Connection monitoring
Ping Reboot, Wget Reboot, Periodic Reboot, LCP and ICMP for link inspection
Connector
4-pin industrial DC power socket
Coordinates
GNSS coordinates via WebUI, SMS, TAVL, RMS
Cumulocity - Cloud of Things
Allows monitoring of: Device Model, Revision and Serial Number, WAN Type and IP, Mobile Cell ID, ICCID, IMEI, Connection Type, Operator, Signal Strength. Has reboot and firmware upgrade actions
Custom registers
MODBUS TCP custom register block requests, which read/write to a file inside the router, and can be used to extend MODBUS TCP Client functionality
Data to server
Extract parameters from multiple sources and different protocols, and send them all to a single server; Custom LUA scripting, allowing scripts to utilize the router's Data to server feature
DDNS
Supported >77 service providers, others can be configured manually
Development tools
SDK package with build environment provided
DHCP
Static and dynamic IP allocation, DHCP relay, DHCP server configuration, status, static leases: MAC with wildcards
Dimensions (W x H x D)
115 x 44.2 x 95.1 mm
DIP
EN 61000-4-11:2004 EN 61000-4-11:2020
DLMS Support
DLMS - standard protocol for utility meter data exchange
DMVPN
Method of building scalable IPsec VPNs, Phase 2 and Phase 3 and Dual Hub support
DNS over HTTPS
DNS over HTTPS proxy enables secure DNS resolution by routing DNS queries over HTTPS
eSIM*
Consumer type eSIM, profile download and removal operations, up to 7 eSIM profiles; does not include data plans
External devices
Possibility to connect external HDD, flash drive, additional modem, printer, USB-serial adapter
Factory settings reset
A full factory reset restores all system settings, including the IP address, PIN, and user data to the default manufacturer's configuration
FLASH storage
256 MB, SPI Flash
Geofencing
Configurable multiple geofence zones
GNSS
GPS, GLONASS, BeiDou, Galileo and QZSS
GPL customization
You can create your own custom, branded firmware and web page application by changing colours, logos, and other elements in our firmware to fit your or your clients’ needs
GRE
GRE tunnel, GRE tunnel over IPsec support
Hotspot
Captive portal (hotspot), internal/external Radius server, Radius MAC authentication, SMS authorisation, SSO authentication, internal/external landing page, walled garden, user scripts, URL parameters, user groups, individual user or group limitations, user management, 9 default customisable themes and optionality to upload and download customised hotspot themes
I/O juggler
Allows to set certain I/O conditions to initiate event
I/O’s
1 x Digital Input, 1 x Digital Output on 4-pin power connector
Ingress Protection Rating
IP30
Input
1 x Digital Input, 0 - 6 V detected as logic low, 8 - 30 V detected as logic high
Input voltage range
9 - 50 VDC, reverse polarity protection, voltage surge/transient protection
JSON-RPC
Management API over HTTP/HTTPS
Keep settings
Update FW without losing current configuration
Load balancing
Balance Internet traffic over multiple WAN connections
Mobile module
4G LTE Cat 6 up to 300 DL/ 50 UL Mbps; 3G up to 42 DL/ 5.76 UL Mbps
Mobile quota control
Mobile data limit, customizable period, start time, warning limit, phone number
Modbus MQTT Gateway
Allows sending commands and receiving data from MODBUS Server through MQTT broker
Mounting options
DIN rail, wall mount, flat surface (all require additional kit)
MQTT
MQTT Broker, MQTT publisher
Multiple PDN
Possibility to use different PDNs for multiple network access and services
Network backup
Wi-Fi WAN, Mobile, VRRP, Wired options, each of which can be used as an automatic Failover
Network protocols
TCP, UDP, IPv4, IPv6, ICMP, NTP, DNS, HTTP, HTTPS, SFTP, FTP, SMTP, SSL/TLS, ARP, VRRP, PPP, PPPoE, UPNP, SSH, DHCP, Telnet, SMPP, SNMP, MQTT, Wake On Lan (WOL), VXLAN
Network topology
Visual representation of your network, showing which devices are connected to which other devices
NTRIP
NTRIP protocol (Networked Transport of RTCM via Internet Protocol)
OpenVPN
Multiple clients and a server can run simultaneously, 27 encryption methods
Operating Humidity
10% to 90% non-condensing
Operating System
RutOS (OpenWrt based Linux OS)
Operating Temperature
-40 °C to 75 °C
Operator
Deutsche Telekom AG
Other
1 x Grounding screw
Output
1 x Digital Output, Open collector output, max output 30 V, 300 mA
Package Manager
The Package Manager is a service used to install additional software on the device
Passthrough
Router assigns its mobile WAN IP address to another device on LAN
PoE (passive)
Possibility to power up through LAN1 port, not compatible with IEEE802.3af, 802.3at and 802.3bt standards, Mode B, 9 - 50 VDC
Port management
View device ports, enable and disable each of them, turn auto-configuration on or off, change their transmission speed, and so on
Power
1 x 4-pin power connector
Power consumption
9 W Max
PPTP, L2TP
Client/Server instances can run simultaneously, L2TPv3, L2TP over IPsec support
Protocol
HTTP(S), MQTT, Azure MQTT
QoS / Smart Queue Management (SQM)
Traffic priority queuing by source/destination, service, protocol or port, WMM, 802.11e
Radiated Immunity
EN 61000-4-3:2006 + A1:2008 + A2:2010 EN IEC 61000-4-3:2020
Regulatory
CE, UKCA, FFC, EAC, UCRF, CITC, ANRT, ICASA, NOM, RCM, IMDA, NTC, E-mark, UL/CSA Safety, CB, RoHS, REACH, IC (ISED), RCM, MTCTE
Reset
Reboot/User default reset/Factory reset button
RMS
Update FW/configuration for multiple devices at once
Routing
Static routing, Dynamic routing (BGP, OSPF v2, RIP v1/v2, EIGRP, NHRP), Policy based routing
Server software
Supported server software TAVL, RMS
SIM
2 x SIM slots (Mini SIM - 2FF), 1.8 V/3 V, external SIM holders
SIM idle protection service
Provides the possibility to configure the router to periodically switch to the unused SIM card and establish a data connection in order to prevent the SIM card from being blocked
SIM PIN code management
SIM PIN code management enables setting, changing, or disabling the SIM card's PIN
SIM switch*
Dual SIM and eSIM, auto-switch cases: weak signal, data limit, SMS limit, roaming, no network, network denied, data connection fail, SIM idle protection
SMS
SMS status, SMS configuration
SNMP
SNMP (v1, v2, v3), SNMP Trap, Brute force protection
SSHFS
Possibility to mount remote file system via SSH protocol
SSTP
SSTP client instance support
Standards
CE: EN IEC 62368-1:2020 + A11:2020, EN IEC 62311:2020 CB: IEC 62368-1:2018 RCM: AS/NZS 62368.1:2022
Status
IMSI, ICCID, operator, operator state, data connection state, network type, CA indicator, bandwidth, connected band, signal strength (RSSI), SINR, RSRP, RSRQ, EC/IO, RSCP, data sent/received, LAC, TAC, cell ID, ARFCN, UARFCN, EARFCN, MCC, and MNC
Status LEDs
3 x WAN type, 2 x Mobile connection type, 5 x Mobile connection strength, 8 x LAN status, 3 x WAN status, 1x Power
Storage formats
FAT, FAT32, exFAT, NTFS (read-only), ext2, ext3, ext4
Stunnel
Proxy designed to add TLS encryption functionality to existing clients and servers without any changes in the program’s code
Supported connection
TCP, USB
Supported connection types
TCP, USB
Supported data formats
8-bit: INT, UINT; 16-bit: INT, UINT (MSB or LSB first); 32-bit: float, INT, UINT (ABCD (big-endian), DCBA (little-endian), CDAB, BADC), HEX, ASCII
Supported languages
Busybox shell, Lua, C, C++
Surge Immunity (AC Mains Power Port)
EN 61000-4-5:2014 + A1:2017
Tailscale
Tailscale offers speed, stability, and simplicity over traditional VPNs. Encrypted point-to-point connections using the open source WireGuard protocol
ThingWorx
Allows monitoring of: WAN Type, WAN IP, Mobile Operator Name, Mobile Signal Strength, Mobile Network Type
Tinc
Tinc offers encryption, authentication and compression in it's tunnels. Client and server support.
TPM*
Identification and authentication module, TPM 2.0 standard
TR-069
OpenACS, EasyCwmp, ACSLite, tGem, LibreACS, GenieACS, FreeACS, LibCWMP, Friendly tech, AVSystem
Traffic Management
Real-time monitoring, wireless signal charts, traffic usage history
USSD
Supports sending and reading Unstructured Supplementary Service Data messages
VLAN
Port and tag-based VLAN separation
VRF support
Initial virtual routing and forwarding (VRF) support
WEB filter
Block list for blocking out unwanted websites, allow list for specifying allowed sites only
WEB UI
Update FW from file, check FW on server, configuration profiles, configuration backup
WireGuard
WireGuard VPN client and server support
ZeroTier
ZeroTier VPN client support
